Description

Edge Series Details

We always have a stock of CNC Plasma Tables available for you. Heavy-weight, extremely powerful, and versatile, the possibilities are endless with our plasma cutters. These machines do not lose their market value, and even after many years of use, we can still trade or sell the unit for you.

Some standard features include:

Steel frame construction

25mm linear rails

Helical low backlash rack and pinion

Hybrid motors with an encoder feedback loop for higher accuracy

60A to 125A plasma powers

Stand-alone controller with touchscreen and easy job loading

Torch Height Controller with raw volt feedback

Waterbed or HVAC table options

FGP provides onsite training, support, and remote login assistance

SOFTWARE TRAINING: FGP is the ONLY company that includes FREE installation and training for all its customers. This training includes machine operation and basic CAD/CAM programming. At the end of the training, any operator can design a job, create machine code and run their CNC!

Edge Series	Specs
Table Size	4’x4’ (1300 x 1300mm) 4’x8’ (1300 x 2500mm) 5’x10’ (1500 x 3000mm)
Frame	Heavy duty steel frame, heat treated and stress relieved
Plasma Power	Options to choose are available: Hypertherm , Miller, Chinese OEM 60A to 125A
Torch Height Controller	Standard with all models
Linear Motion	Taiwan HIWIN 25 mm rails for X,Y
Transmission	Taiwan Miko Helical rack and pinion for X,Y Taiwan TBI ball screw for Z Optional: All-axis ballscrew transmission system.
Motors and Drives	Hybrid / Servo motors with closed-loop feedback
Table	Steel grill table top with waterbed or HVAC
Controller	Stand-along touchscreen Starfire control system with graphical user interface
Lubrication	Maintenance-free self-lubricating bearings
Travel	900 IPM rapid travel
Install & training	FGP offers free installation and training on all machines! Training in software, CNC, design, CAM, and maintenance

Standard Features

Industrial plasma cutting table with waterbed / HVAC
25mm linear rails and low backlash helical racks
60A to 125A plasma cutter for steel and stainless
Torch height controller to follow material with raw voltage feedback
Onscreen assistance and job simulation
Touchscreen control interface with easy load and shape library
Manual override of spindle speed and feed speed during runs

Special Features

Single-phase or 3-phase power connection 220 Volts
Plasma power 60A – 125A options ( cutting and gouging up to 32 mm (1-1/4″).
Intuitive controller with graphical user interface
Torch Height Controller (THC)
High torque, high-speed motors
Integration with Hypertherm, Miller, Chinese or other plasma models
Heavy construction (Weight over 1,400 KG)
Input Gcode commands (SheetCAM, AutoCAD, etc..)
Waterbed or HVAC options are available
